CO2 Laser Cutting Machine for Wood and Nonmetal
CO2 single head laser engraving and cutting machine series adopts international advanced DSP control technology, they have the high speed, high cutting accuracy and high stability, the quality and price ratio is very high. The main system can be commanded by U-disk without PC connection. It has the functions of imitative cutting, color separating cutting, non-stop cutting once off power, etc.
Key Features
Adopts advanced international DSP control technology for high speed, accuracy, and stability.
Supports U-disk operation without PC connection for convenience and flexibility.
Functions include imitative cutting, color-separating cutting, and power-off resume cutting.
Versatile cutting capability for both non-metal materials (acrylic, wood, ABS, bamboo, etc.) and metal materials (carbon steel, stainless steel).
High precision suitable for handicrafts, advertising characters, and multi-material processing.
Combines multiple functions in one machine, enhancing efficiency and reducing costs.
Ideal for diverse industrial applications, especially in advertising and craft production.
Technical Specifications
| Model | LS-1390 |
| Laser Type | CO2 laser |
| Laser Power | 130W |
| Engraving Speed | 0-64 m/min |
| Cutting Speed | 0-36 m/min |
| Repeat Accuracy | ±0.05mm |
| Moving System | CNC control system |
| Cooling Mode | Water-cooling and protection system |
| Overall Power Consumption | ≤1250W |
| Working Voltage | 220±10% 50Hz(60Hz) |
| Operating Temperature | 0~45ºC |
| Operating Humidity | 5%-95% |
| Controlling Software | Ruida Control Card |
| Graphic Supported Format | CAD, MP, JPG, PNG, TIF, PCX, TAG, IOO, GIF, PLT |
| Working Area | 1300mm × 900mm |
| Gross Weight | 550KG |
| Package Dimension | 2000mm × 1600mm × 1270mm |
Applications
